1024 channels
Dual Band
TDMA Digital Function
Encryption Function
Up to 50000 CSV contacts
Recording( optional)
GPS ( optional )
GENERAL
Frequency
136-174MHZ/400-480MHZ
Channel capacity
4000
Channel space
25KH2/12.5KHZ
Frequency stability
±0.5ppm
Voltage
7.4V DC+20%
Antenna impedance
50Ω
Work temperature
-30℃ to +60℃
Battery capacity
2800mAh
Size(include battery, exclude antenna)
123x63x39mm
Weight(include battery and antenna)
280g
TRANSMITTER
Output power
5W
4FSK Digital Mode
12.5KHZ(data only): 7k60FXD
FM Hum & Noise
≥40dB@12.5KHz:>45dB@25kH2
Modulation maximum deviation
≤+2.5KHZ@12.5KHZ
RECEIVER
Sensitivity (Digital)
≤-119dBm@5% BER
Adjacent channel selectivity
-65dB@12.5/25kHz
Audio output power
>1W
Audio distortion
<5%
