| STANDARD SPECIFICATIONS |
| Frequency | UHF:400-470MHz |
| Channel capacity | 16 |
| Channel space | 12.5KHz/25KHz |
| Voltage | DC7.4 |
| Antenna impedance | 50Ω |
| Battery capacity | 2600mAH |
| Work temperature | -25℃ to +55℃ |
| Size(include battery, exclude antenna) | 110*60*38mm |
| Weight(include battery and antenna) | 118g |
| RECEIVING PERFORMANCE |
| Usable Sensitivity | 0.2uV |
| Squelch Opening Sensitivity | ≤0.18uV@5 |
| Receiver Residual Output | ≤-45dB/≤-35dB |
| Modulated Reception Bandwidth | +7KHz/±3.5KHz |
| Adjacent Channel Selectivity | 60dB@12.5KHz,70dB@25KHz |
| Intermodulation Immunity | 65dB |
| Receiving Current Consumption | ≤400mA |
| Spurious Response Immunity | ≥70dB |
| Standby Current | ≤30mA |
| TRANSMITTING PERFORMANCE |
| Transmitting Power | 5W |
| Emission Current | ≤1300mA |
| Modulation distortion | ≤5% |
| Residual frequency modulation | ≤-45dB |
| Adjacent channel power | ≥65dB/v60dB |
| Emission stray | ≥70dB |
| Frequency stability | ≤+2.5ppm |
| Maximum frequency deviation | ±5kHz/±2.5kHz |
