UHF 400-470MHZ
99 channel
Large battery capacity
50 CTCSS, 105 DCS
Time-out Timer(TOT)
Auto Power save function
VOX Function
Low battery alert
Scan function
GENERAL
Frequency
UHF:400-470MHz
Channel
99
Channel space
25/12.5KHZ
Frequency stability
±2.5ppm
Voltage
7.4vdc
Antenna impedance
50Ω
Work temperature
-20℃ to +55℃
Battery capacity
3000mAh
Size(include battery, exclude antenna)
60x40x150mm
Weight(include battery and antenna)
280g
TRANSMITTER
Output power
≤10W
Modulation
16K0F3E@25KHz,11K0F3E@12.5KHz
FM Noise
≤45dB@25KHz
Max Frequency Deviation
≤±5KHz
RECEIVER
RX Sensitivity
0.25uV(12dB SINAD)
Adjacent channel selectivity
≥55dB@12.5KHZ
Audio output power
1W@16 ohms
Audio distortion
≤5%
