IP68 Waterproof level
10W High Power
Wireless Frequency Copy
Frequency Hopping Encryption
Battery Level Display
128 Channel
Type-C Port
GENERAL
Frequency
134-174MHz/400-520MHZ
Channel capacity
128
Channel space
25/12.5 KHZ
Frequency stability
±2.4ppm
Voltage
7.4V
Antenna impedance
50Ω
Work temperature
-20℃ to +60℃
Battery capacity
2600mAh
Size(include battery, exclude antenna)
120x62x40 mm
Weight(include battery and antenna)
283g
TRANSMITTER
Output power
10W
Modulation limit
≤4.2
FM Hum & Noise
45dB
Modulation maximum deviation
≥70dB
RECEIVER
Sensitivity
25dB
Adjacent channel selectivity
≤55dB
Audio output power
≥400mW
Audio distortion
≤3%
