Recording(Optional)
Talkaround
Call Alert
Call Repeater
SMS
Repeater
Private/Group/All Call
1000 Digital Contacts
64 Channel
GENERAL
Frequency
400-470MHZ
Channel capacity
64
Channel space
12.5KHZ
Charging Time
4-5 hours
Voltage
7.4V DC
Work temperature
-20℃ to +50℃
Battery life @ 5/5/90
Analog:11h /Digital:15h
Battery capacity
1600mAh Li-ion
Size(include battery, exclude antenna)
113x58x38mm
Weight(include battery and antenna)
240g
TRANSMITTER
Output power
4W
4FSK Digital Mode
12.5kHz Data/Voice:7K60FXW 12.5KHz Data:7K60FXD
Modulation Accuracy
5%@25℃
Audio Response
+1/-3 dB
RECEIVER
Sensitivity (Digital)
≥-117.4dBm (BER ≤5%)
Adjacent channel selectivity
≥60dB
Audio output power
≤1W@16Ω
Audio distortion
≤5%
